High-Frequency Ballast Compactor for Tiltrotators
The Rail Tamper RST is a proven high-frequency ballast compactor designed for excavators and cranes equipped with tiltrotators. Weighing only 680 kg and featuring a replaceable adapter, it suits both small and large machines. With a powerful 60 Hz vibration frequency, it ensures efficient and quiet ballast packing.
The latest model includes reinforced legs, a newly developed bearing system, and a pressure-compensated hydraulic circuit with safety valve. Delivered with a 400 mm packing depth adjustment plate as standard. Ideal for fast and precise track tamping.
✅ Properties
- 60 Hz high-frequency vibration for optimal compaction
- Tiltrotator compatible – easy maneuvering
- Suitable for 12–24 ton machines
- Pressure-compensated hydraulic system with safety valve
- Quick installation with bolted handling bracket
ℹ️ Technical Specification
- Weight: 680 kg
- Packing force: 7,500 kg
- Packing depth: 400 mm (standard), 455 mm (with accessory)
- Oil flow: 50–170 l/min
- Max pressure: 350 bar
- Machine range: 12–24 tons
- Accessories: Handling bracket, compactor plate, hydraulic quick couplers, depth adjustment plate
